Porkka F - Evaporator Replacement; Probe and Plug Detachment; Ribbon Cable Disconnection; Evaporator Box Removal and Replacement

21
(a)
(a)
(c)
(b)
(d)
(d)
(e)
Technical and Service manual
Porkka reserves the right to make product alterations at any time and can not be held responsible for any printing errors or omissions.
Inventus upright refrigerators and freezers
1. Loosen two ribbon screws (a).
Remove temperature probe (b).
Loosen magnet valve screws (c, F models only).
2. Loosen four screws (d) and plastic plug
(e).
3. Remove the ribbons. 4. Lift up the evaporator box and change
the evaporator.
Evaporator
