Label
Name Range Default
Level
AUXILIARY THERMOSTAT
ACH
Kind of action for auxiliary relay CL; Ht Ht Pr2
SAA
Set Point for auxiliary relay
[-55.0 to 150°C]
[-67 to 302°F]
5 Pr2
SHy Differential for auxiliary relay
[0.1 to 25.5°C]
[1 to 45°F]
2 Pr2
ArP Probe selection for auxiliary relay nP; P1; P2; P3 nP Pr2
Sdd Aux.output working during defrost
n; Y no Pr2
ALARMS
ALP
Probe setting for temperature
alarm
P1; P2; P3; P4 P1 Pr2
ALC
Temperature alarms configuration
rE; Ab Ab Pr2
ALU
MAXIMUM temperature alarm
[-55.0 to 150.0°C]
[-67 to 302°F]
110,0
Pr1
ALL minimum temperature alarm
[-55.0 to 150.0°C]
[-67 to 302°F]
-50,0
Pr1
AFH
Temperature alarm and fan
differential
[0.1 to 25.5°C]
[1 to 45°F]
2,0 Pr2
ALd Temperature alarm delay 0 to 255 min 15 Pr2
dot
Temperature alarm delay with
door open
0 to 255 min 15 Pr2
dAo
Delay of temperature alarm at
start up
0.0 to 23h50min, res. 10 min 1,3 Pr2
AP2
Probe for temperat. alarm of
condenser
nP; P1; P2; P3; P4 P4 Pr2
AL2
Condenser for low temperat.
alarm
[-55.0 to 150.0°C]
[-67 to 302°F]
-40 Pr2
AU2
Condenser for high temperat.
alarm
[-55.0 to 150.0°C]
[-67 to 302°F]
110 Pr2
AH2
Differential for condenser
temperature alarm recovery
[0.1 to 25.5°C]
[1 to 45°F]
5 Pr2
Ad2
Condenser temperature alarm
delay
0 to 254 min , 255=nU 15 Pr2
dA2
Delay of cond. temper. alarm at
start up
0.0 to 23h50min, res. 10 min 1,3 Pr2
bLL
Compressor off because of
condenser low temperature alarm
n(0); Y(1) n Pr2
AC2
Compr. off for condenser high
temperature alarm
n(0); Y(1) n Pr2
AUXILIARY OUTPUT
tbA Alarm relay disabling n=no; Y=yes y Pr2
buM
Buzzer silencing n(0); Y(1) yes Pr2
oA4 TRIAC configuration (28-29)
ALr = alarm; dEF = do not select it; Lig
=Light; AUS =AUX; onF=always on; Fan=
do not select it; db = do not select it; dF2 =
do not select it
onF Pr2
AoP Alarm relay polarity (oA4=ALr) oP; CL CL Pr2
DIGITAL INPUT
i1P Digital input polarity oP=opening;CL=closing cL Pr1
i1F Digital input configuration EAL; bAL; PAL; dor; dEF; Htr; AUS dor Pr1
did Digital input alarm delay 0 to 255 min 5 Pr1
i2b Second Digital input on base n , y CL Pr1
i2P Digital input polarity oP=opening;CL=closing EAL Pr1
i2F Digital input configuration EAL; bAL; PAL; dor; dEF; Htr; AUS 0 Pr1
d2d Digital input alarm delay 0 to 255 min
15 Pr2
nPS
Number of activation of pressure
switch
0 to 15 F-C Pr2
odC
Compress and fan status when
open door
no; FAn; CPr; F_C yes Pr2
rrd
Regulation restart with door open
alarm
n; Y no Pr2
LES
Light off during energy saving
status
n; Y 0 Pr2
HES
Differential for Energy Saving
[-30 to 30°C]
[-54 to 54°F]
0 Pr2
OTHER
Adr Serial address 1 to 247 1 Pr1
PbC Kind of probe PtC; ntC ntC Pr2
onF on/off key enabling nu, oFF; ES oFF Pr2
dP1 Room probe display read only - Pr1
dP2 Second probe display read only - Pr1
dP3 Third probe display read only - Pr1
dP4 Fourth probe display read only - Pr1
rSE Current set point read only Pr1
rEL Software release read only 9.4 Pr2
Ptb Map code read only - Pr2
