ROUTER ACCESSORIES AND
ATTACHMENTS FOR DOOR HANGING OPERATIONS
Model 59829 Accessory Package (to in¬
crease the capacity of the 59380 to 3
hinge 8' to 9' doors)—Includes 2 long
guide rails.
Model 59380 Hinge Butt Template—Easy
to operate, this new hinge butt template
will mortise a door and butt of any length
and hinge size, using standard acces¬
sories. Features include spring loaded
nails that stay up prior to driving and can
be removed with a claw hammer, loca¬
tors to transfer measurements from jamb
to door, gauges to allow for weather
stripping, end gauges for each end of
the template and a full length locator
with each template section.
Accommodates
M ^ el Jambs Includes
" ’ and Hinges
_ Doors _
6'6* 3 template sections, two guide rails,
59380 6'8* 3' to 6' 2 each 5' and 7" end gauges,
_ T _ 48256 wrench, and operating manual
3", 3V2", 4", 4Va ", 5", 51 / 2 " and 6" jamb
gauges are available as accessory equip¬
ment for setting the 59380 when wood
doors are to be fitted to metal jambs.
Model 59381 Hinge Butt Template Kit—
Includes 59380 Hinge Butt Template,
43446 Mortising Bit, 42042 Template
Guide, 42237 Lock Nut, 59824 Carrying
Case, Operating Manual.
ACCESSORIES
Bit No.
Diameter
(inches)
Type
Use With
Template
Guide No.
Use
43466
Vi H.S.
42042
For square comer &
Vt" radius butts
43477
Vi
Carbide
42042
For square corner &
V*" radius butts
43449 %
H.S.
42039
Square corner butts
43440
% Carbide
42039
Square corner butts
•43630
IV*
H. S.
42048
V Radius Butts
♦ 43745 IV*
Carbide
42048
%’ Radius Butts
42237
Lock Nut for attaching template guides to router
•Requires appropriate arbor
Model 59839 Accessory Package (to in¬
crease the capacity of the 59380 to 4
hinge, 6'-7' doors, 3 and 4 hinge, 7'-8'
doors, 4 hinge, 9' doors). Includes 3
guide rails, 1 template section.
No. 59824 Carrying Case.
No. 59825 3" Jamb Gauge.
No. 59826 3%" Jamb Gauge,
No, 59827 4" Jamb Gauge.
No. 59828 414" Jamb Gauge,
No. 59832 5" Jamb Gauge.
No. 59830 51 / 2 " Jamb Gauge.
No. 59831 6" Jamb Gauge.
No. 42042 Router Template Guide.
No. 42234 Corner Chisel. For squaring
hinge mortises.
Model 513 Extra-Heavy-Duty Lock Mor¬
tising Kit. Permits quick, accurate cut¬
ting of mortises for door box locks. The
machine is fully adjustable for cutting
mortises in varying sizes up to 7" long,
1%" wide and 5" deep (using 43631
Bit). Includes lock mortiser; height rod;
%" and %" Bits; extra-heavy-duty 114
HP, 22,000 rpm, 8 amp motor with an
integral spindle; and operating manual.
ACCESSORIES
No. 43622 3 / 4 " H.S. Bit.
No. 43623 ■ %" H.S. Bit.
No. 43624 %" H.S. Bit.
No. 43625 i«/ I4 " H.S. Bit.
No. 436261" H.S. Bit.
No. 43627 H/, 4 " H.S. Bit.
No. 43628 114" H.S. Bit.
No. 43630 11 / 4 " H.S. Bit.
No. 43631 1 % " H.S. Bit.
No. 43703 3 /4" Carbide Bit.
No, 43704 1" Carbide Bit.
No. 43745 1V4" Carbide Bit.
No. 42081 Height Rod.
Model 517 Lock Face Template— Used
to quickly rout lock faces on door
after the mortise for the box lock itself
has been completed. Automatically self¬
centering and self-beveling.
Includes Template, 42024 Template
Guide and Operating Manual.
Net Wt. 214 Lbs., Shpg. Wt. 3 Lbs.
(Max Mortise 1 % " x 814 ")
ACCESSORIES
No. 42024 Template Guide.
No. 42237 Lock Nut for attaching tem¬
plate guides to router.
No. 43449 s/s " Quality Steel Bit with %"
Dia. Shank.
No. 43440 %" Carbide Tipped Bit with
14" Dia. Shank.
No. 42234 Corner Chisel.
Accessories
ROUTER BASES
Model No.
Type
Use With
Model(s)
5141
Conventional
514, 5142
5361
Conventional
536, 5372
5371
“D” Handle
537, 5372
6301
Conventional
350, 630,
670, 690
" ■ 5022
Offset w/Guide
312, 3102
*5031
Offset
311, 3102
5036
Conventional
313, 3102
3101
Laminate Trimmer 310, 3102
1001
Conventional
100
•See Laminate Trimmer Accessories
ROUTER SUB BASES
Model No.
Use With Model(s)
10695
514
42186
“All others”
LAMINATE TRIMMING KIT
Model 5023—For edge trimming of plas¬
tic laminates and wood veneers. Carbide-
tipped combination bit handles both
flush and bevel trimming operations.
Micrometer adjustment control of non¬
marking nylon roller guide assures
smooth, accurate cutting.
Includes Roller, Carrier Assembly, Sub-
Base, 43239 Carbide Tipped Combination
Bit and Operating Manual.
Net Wt. 1/2 lb., Shpg. Wt. % lb.
SHARPENING ATTACHMENTS
For fast, accurate sharpening of router
bits and cutters. Adjustable for one, two
or three cutting edge bits with 14" or 14 "
shanks, also %" hole cutters. Using
accessory adapters; and %"
shank bits, can also be sharpened.
Includes Attachment, Arbor, 48077 Grind¬
ing Wheel, 42127 14" Bit Adapter, 48245
Wrench, 48270 Wrench, Tripod Router
Stand and Operating Manual. Net Wt.
1 lb., Shpg. Wt. 2 lbs.
No. 5011—For old Models 350 and 150,
and Models 100, 630, 670 and 690.
No. 5010—For Models 536 and 537.
No. 5013—For Model 514.
ACCESSORIES
No. 48040 Dressing Stone.
No. 48077 Grinding Wheel. 14" shank.
No. 42078 Grinding Wheel. %" hole.
No. 42130 Adapter. For shank diam.
bits.
No. 42133 Adapter. For %" shank diam.
bits.
17
