8 - ENG
A10382
MODEL NO. C3101
Running Horsepower 1.6
Bore 2-3/8"
Stroke 1.35"
Voltage/Hertz/Phase 120/60/1
Minimum Branch Circuit 15 Amp
Fuse Type Time Delay
Tank Size 4.3 Gallon
Approx. Cut-In 120 PSI
Approx. Cut-Out 150 PSI
SCFM @ 40 psig 7.8
SCFM @ 90 psig 5.7
SPECIFICATIONS
GLOSSARY
Become familiar with these terms before operating the unit.
CFM: Cubic feet per minute.
SCFM: Standard cubic feet per minute; a unit of measure of air delivery.
PSIG: Pounds per square inch gauge; a unit of measure of pressure.
Code Certification: Products that bear one or more of the following marks: UL,
CUL, ETL, CETL, have been evaluated by OSHA certified independent safety
laboratories and meet the applicable Underwriters Laboratories Standards for
Safety.
Cut-In Pressure: While the motor is off, air tank pressure drops as you continue
to use your accessory. When the tank pressure drops to a certain low level
the motor will restart automatically. The low pressure at which the motor
automatically restarts is called "cut-in" pressure.
Cut-Out Pressure: When an air compressor is turned on and begins to run,
air pressure in the air tank begins to build. It builds to a certain high pressure
before the motor automatically shuts off - protecting your air tank from pressure
higher than its capacity. The high pressure at which the motor shuts off is
called "cut-out" pressure.
Branch Circuit: Circuit carrying electricity from electrical panel to outlet.
DUTY CYCLE
This air compressor pump is capable of running continuously. However, to
prolong the life of your air compressor, it is recommended that a 50%-75%
average duty cycle be maintained; that is, the air compressor pump should not
run more than 30-45 minutes in any given hour.
Accessories for this unit are available at the store the unit was purchased.
ACCESSORIES
