Porter-Cable PCB270TS - Square Nuts; Parts List

– 33 –
I.D. Description Size Qty I.D. Description Size Qty
2389 WHEEL
#06
1 26PT COMPRESSION SPRING 1
2390 COMPRESSION SPRING 1 26VG WIRE CONNECTOR 1
2552 HANDLE
#06
1 26VH WIRE CONNECTOR 1
09JK WRENCH 1 26YD LEAD WIRE ASS’Y 1
0B98 BEVEL GEAR 1 26YE LEAD WIRE ASS’Y 1
0BAC SET NUT 1 26YF LEAD WIRE ASS’Y 1
0BAE ARBOR COLLAR 1 28DX WORM 1
0GCM BEVEL GEAR 1 28DY BEVEL GEAR 2
0HVX BALL BEARING 2 28RA SWITCH BOX COVER 1
0J3V WRENCH HEX.
6MM
1 28Z5 ANCHOR BLOCK 2
0J4D FLAT WASHER
φ5*10-1
2 28Z7 CR. RE.COUNT HD. TAPPING SCREW 2
0J4F FLAT WASHER
φ8*16-2.5
4 293H PUSH STICK 1
0J4U FLAT WASHER
φ6*18-1.5
1 297W HARDWARE BAG ASS’Y - S 1
0J4W FLAT WASHER
φ8.2*18-1.5
4 297Y HARDWARE BAG ASS’Y - Q 1
0J5A FLAT WASHER
φ5*16-2
1 2LXE CIRCUIT BREAKER SWITCH ASS’Y 1
0J6T FLAT WASHER
/16*3/4-1/16
4 2NWX DUST GUARD 1
0J78 FLAT WASHER
1/4*1/2-3/32
2 2PHA CR. RE. TRUSS HD. TAPPING SCREW
M5*0.8-12
24
0J7U FLAT WASHER
5/8*1 3/4-11/64
1 2PHX HEX. SOC. TRUSS HD. SCREW
M5*0.8-8
2
0J8K FLAT WASHER
1/4*3/4-1/16
1 2TUY BLADE GUARD ASS’Y 1
0J8Z FLAT WASHER
21/64X3/4-1/16
1 2UZU SPACER 1
0J94 SPRING WASHER
φ8
4 2V3E BLADE GUARD(RIGHT) 1
0JAF EXTERNAL TOOTH LOCK WASHER
φ5
4 2W7L CONNECTOR BOX 1
0JB2 WAVE WASHER
WW-12
2 2W7M CONNECTOR BOX COVER 1
0JCH SPRING PIN 5 2W7Q BODY SHELL(R)
#GL
1
0JG4 PARALLEL KEY 2 2W7R BODY SHELL(L)
#GL
1
0JP3 HEX. HD. BOLT
M8*1.25-12
6 2W7S BODY SHELL(F)
#GL
1
0JPU HEX. HD. BOLT
M8*1.25-20
4 2W7T EXTENTION WING
#GL
2
0JUL HEX. SOC. HD. CAP BOLT
M6*1.0-20
6 2W7U REAR BRACKET
#06
2
0JX7 HEX. SOC. SET SCREW
M6*1.0-6
9 2W7V TABLE
#GL
1
0K05 HEX. SOC. TRUSS HD. SCREW
M8*1.25-20
6 2W7W DUST GUARD ASS’Y
#GM
1
0K19 HEX. HD. SCREW AND WASHER
M10*1.5-25
6 2W89 TABLE SUPPORT ASS’Y
#06
1
0K24 HEX SOC. HD. CAP SCREW
M8*1.25-35
4 2W8J REAR RAIL(L) 1
0K2L HEX.SOCKET HD.CAP SCREWS
M8*1.25-30
4 2W8K REAR RAIL (R) 1
0K4T CR.-RE. TRUSS HD. SCREW
M5*0.8-20
1 2W8M BODY 1
0K5B CR. RE. COUNT HD. SCREW
M6*1.0-12
2 2W8N RACK 2
0K5T CR. RE. COUNT HD. SCREW
M5*0.8-10
4 2W8P CLAMP BAR 1
0K7D CR. RE. ROUND WASHER HD. SCREW
M6*1.0-10
4 2W8Q HEIGHT LEVER SEAT 1
0K7F CR. RE. ROUND WASHER HD. SCREW
M5*0.8-8
8 2W8T RIVING KNIFE 1
0K7K CR. RE. ROUND WASHER HD. SCREW
M6*1.0-12
2 2W8U DUST COLLECTOR 1
0K94 CR. RE. TRUSS HD. TAPPING SCREW
M5*12-16
1 2W8V SET PLATE 1
0K9P CR. RE. TRUSS HD. TAPPING SCREW
M6*14-12
1 2W8W DUST COLLECTOR JOINT 1
0KA0 CR.RE. PAN HD. TAPPING SCREW
M5*12-20
2 2W8Z ELEVATION SHAFT 1
0KAE CR.RE. PAN HD. TAPPING SCREW
M5*0.8-10
4 2W90 CENTER SHAFT 1
0KB9 CR.RE. PAN HD. TAPPING SCREW
M5*16-10
7 2W91 CENTER SHAFT 1
0KC8 CR. RE. TRUSS HD. TAPPING SCREW
M4*16-16
7 2W93 SET BOLT
M8*1.25
6
0KFG CR. RE. PAN HD. SCREW
M5*0.8-12
4 2W94 HEIGHT REGULATER BOLT 1
0KK9 SLOTTED PAN HD.SCREW
M6*1.-20
2 2W95 LOCKING ROD 1
0KL1 CR.RE. PAN HD. ROUND NECK SCREW
M6*1.0-12
2 2WBS RAIL (L) 1
0KMS HEX. NUT
M6*1.0 ,T=5
3 2WBT RAIL (R) 1
0KMT HEX. NUT
M8*1.25, T=5
2 2WBU MOTOR PULLEY 1
0KMY HEX. NUT
M8*1.25, T=6.5
2 2WBV PULLEY 1
0KN3 HEX. NUT
M16*1.5,T=10
1 2WCH CUTTER SHAFT 1
0KNV HEX. NUT
5/8*18UNF T=8
2 2WG1 HANDLE ASS’Y 1
0KQF CROWN NUT
M8*1.25, T=18
2 2WGA KNOB ELEVATION ASS’Y 1
0KQP SQUARE NUT
M8*1.25 T=6.5
6 2WHH BODY SHELL
#GL
1
0KQW LOCK NUT
M5*0.8 T=5
3 2WJA SET PLATE 1
0KQX NUT
M6*1.0 T=6
3 2WJB SET PLATE 1
0KRR SERRATED TOOTHED HEXAGON FLANGE NUT
M8*1.25, T=7.5
4 2WWD MOTOR ASS’Y 1
0KSC STRAIN RELIEF 1 2X19 KICK BACK PAWL ASS’Y 1
0KTA
STRAIN RELIEF 5 2X1A MITER GAUGE ASS’Y 1
0LMK LOCKING CABLE TIE 1 2X1B RIP FENCE ASS’Y 1
0QGR COMPRESSION SPRING 1 2X1D CLAMP BAR 1
0R25 COLLAR 1 2X1E LOCK HANDLE 1
10PM COPPER BUSH 4 2X1G SPECIAL NUT 1
145M SPRING PIN 2 2X1Q DRIVE BELT,POLY-V BELT 1
151G O-RING ROD 2 2X1T PUSH IN PIN 2
20LW CR.RE. PAN HD. SCREW & WASHER
M5*0.8-16
10 2X1U SLEEVE-RUBBER 1
22VD PARALLEL PIN 1 2X23 ROCKER SWITCH 1
22VF SLEEVE 1 2X55 SPACER 1
237F BEVEL GEAR 1 2X5N LEAD WIRE ASS’Y 1
237G REINFORCE PLATE 1 2X5P POWER CABLE 1
237T SET PLATE 2 2X64 WHEEL CAUTION STICKER 1
237V DUST GUARD 1 2X65 WHEEL CAUTION STICKER 1
237W GUIDE BLOCK 1 2X79 SCALE (L) 1
237X SPONGE 2 2X7A SCALE (R) 1
237Y WHEEL
#06
1 2X7H CAUTION LABEL 1
237Z SET PLATE 1 2X7J LABEL 1
238G LOCATION SEAT 2 2X7K CAUTION STICKER 1
238K ARM BRACKET 2 2XKU HARDWARE BAG ASS’Y - U 1
238S POINTER 1 2XZ9 COLLAR 1
238T ROLLING WHEEL 2 2YBD WARNING LABEL 2
239G LINK PLATE 1 2YBU TRADE-MARK LABEL 1
239H SIDE COVER(LEFT) 1 2YEW INSTRUCTIONS MANUAL 1
239J SIDE COVER(RIGHT) 1 2YQ2 BLADE 1
23BA SCREW
M6*1.0
2 2YQ3 HEX. SOC. HD. CAP BOLT
M8*1.25-75
4
23CN HEX.SOCKET HD.CAP SCREWS
M6*1.0-40
4 2YR5 BUSH 2
23KE HEX. NUT
M16*1.5,T=7
1 2YRC HARDWARE BAG ASS’Y - T 1
23KS BALL BEARING 2 2YRD HARDWARE BAG ASS’Y - R 1
255N HEX.SOCKET HD.CAP SCREWS
M8*1.25-20
4 2YRG HARDWARE BAG ASS’Y - P 1
255V WASHER 1 2YRK HANDLE BAR ASS’Y 1
25JY SWITCH MOUNTING
#06
1 2YVD PLUNGER HOUSING ASS’Y 1
25MZ SWITCH BOX 1 2YXD COVER 1
2Z22 TILTING SCALE 1
10 IN. (254 MM) STATIONARY TABLE SAW
PARTS LIST FOR TABLE SAW
PARTS LIST
