2
SECTION PAGE
PRODUCT SPECIFICATIONS ....................................................................................... 2
SAFETY GUIDELINES - DEFINITIONS ......................................................................... 3
POWER TOOL SAFETY ................................................................................................. 4
BAND SAW SAFETY ...................................................................................................... 5
ELECTRICAL REQUIREMENTS AND SAFETY ............................................................ 6
TOOLS NEEDED FOR ASSEMBLY ............................................................................... 9
CARTON CONTENTS .................................................................................................... 9
KNOW YOUR BAND SAW ............................................................................................. 11
GLOSSARY OF TERMS ................................................................................................. 12
ASSEMBLY AND ADJUSTMENTS ................................................................................. 13
OPERATION ................................................................................................................... 19
MAINTENANCE .............................................................................................................. 21
TROUBLESHOOTING GUIDE ....................................................................................... 22
ACCESSORIES AND ATTACHMENTS .......................................................................... 24
PARTS LIST .................................................................................................................... 25
WARRANTY ................................................................................................................... 28
MOTOR BLADE
Amps ............ 2.5 A Width ................. 1/8, 1/4, 3/8 in.
Voltage ......... 120 V (3.2, 6.4, 9.5 mm)
Hz ................. 60 Length ............... 59-1/2 in. (1511 mm)
Speed ........... 1720 RPM (No load) CUTTING CAPACITY
Type .............. Induction Throat ................ 9 in. (228 mm)
TABLE SIZE 12-5/16 x 11-7/8 in. Height ................ 3-11/32 in. (85 mm)
(313 x 302 mm) SAWDUST PORT 2-1/2 in. O.D. (63.5 mm)
To avoid electrical hazards, re hazards or damage to the tool, use proper circuit protection.
Use a separate electrical circuit for your tools. This band saw is wired at the factory for 120 Volt
operation. It must be connected to a 120 Volt / 10 Ampere time delay fuse or circuit breaker. To
avoid shock or re, replace power cord immediately if it is worn, cut or damaged in any way.
2016/10 Printed in China
WARNING
!
TABLE OF CONTENTS
PRODUCT SPECIFICATIONS
