Porter-Cable PCXB310BS - Parts List

25
9 IN. (228 MM) SINGLE SPEED BAND SAW
PARTS LIST FOR BAND SAW
PARTS LIST
ID Description Size Q'ty ID Description Size Q'ty
X7F7 Lower door 1 X7DB 6P4 clip 2
X7F6 Hex screw M6*10 2 X7DA Power cord 1
X7F5 Spring washer 6 X7D9 Hex screw M8*25 2
X7F4 Nut 4 X7D8 Flat washer 2
X7F3 Philips screw M4*10 4 X7D7 Motor 1
X7F2 Blade tracking window 1 X7D6 Locking knob 1
X7F1 Upper door 1 X7D5 Eccentric locking knob 2
X7F0 Blade 1 X7D4 Flat washer 2
X7EZ Circlip for shaft 2 X7D3 Hex screw M6*25 2
X7EY Ball bearing 4 X7D2 Adjusting gear 1
X7EX Internal circlip φ26 4 X7D1 Adjusting handle base 1
X7EW Philips screw M5*12 6 X7D0 Adjusting handle 1
X7EV Tire 2 X7CZ Dust port 1
X7EU Idler pulley 1 X7CY Hex bolt M6*20 4
X7ET Carriage bolt M8*70 1 X7CX Hex nut 5
X7ES Brush 1 X7CW Shaft 1
X7ER Brushing sleeving 1 X7CV Locking spring 1
X7EQ Upper wheel shaft 1 X7CU Gear handle 1
X7EP Upper wheel shaft base 1 X7CT Table pointer 1
X7EN Washer 2 X7CS Hex bolt M6*25 1
X7EM Connection shaft 1 X7CR Table insert 1
X7EL Blade wheel 2 X7CQ Work table 1
X7EK U type support 1 X7CP Table locking knob 1
X7EJ Carriage bolt M8*85 1 X7CN Guide block 2
X7EH Hex nut 2 X7CM Angle support 1
X7EG Switch 1 X7CL Hex bolt M6*12 4
X7EF Switch plate 1 X7CK Hex screw M6*16 2
X7EE Locking pad 1 X7CJ Buttery bolt 1
X7ED Guide base 1 X7CH Flat washer 2
X7EC Philips screw M5*10 6 X7CG Slide bar 1
X7EB Guide plate 1 X7CF Miter gauge knob 1
X7EA Plate spring 1 X7CE Miter gauge 1
X7E9 Philips screw ST3.9*10 1 X7CD Pan head screw with at M5*8 1
X7E8 Slide board 1 & spring washer
X7E7 Upper guide slide bar 1 X7CC Miter gauge pointer 1
X7E6 Hex screw M4*4 5 X7CB Lower support shaft 1
X7E5 Pin 4 X7CA Lower blade guide support 1
X7E4 Upper blade guide support 1 X7C9 Spring washer 1
X7E3 Upper support shaft 1 X7C8 Capacitor 1
X7E2 Flat washer 2 X7C7 Philips screw+at washer M4*6 2
X7E1 Ball bearing 2 X7C6 Capacitor box 1
X7E0 Bearing fastening screw 2 X7C5 Wavy washer φ6 1
X7DZ Hex screw M5*10 6 X7C4 Lower blade guide support base 1
X7DY Hex screw M5*15 1 X7C3 Hex bolt M6*40 1
X7DX Pan head screw with at M4*8 6 X7C2 Open end wrench 1
& spring washer X7C1 4 mm hex wrench 1
X7DW Belt 1 X7C0 2 mm hex wrench 1
X7DV Hex nut M12*1.5 1 X7BZ Warning label 1
X7DU Spring washer 1 X7BY Logo label 1
X7DT Lower wheel shaft 1 X7BX Motor label 1
X7DS Hex screw M5*10 1 X7BW Rotating label 1
X7DR Flat washer 1 X7BV Instruction manual 1
X7DQ Driven pulley 1 X7BS Upper guide slide bar assembly 1
X7DP Guide plate 1 X7BR Upper blade guide support 1
X7DN Hex nut 1 X7BQ Upper bearing guide assembly 1
X7DM Hex screw M6*8 2 X7BP Upper door assembly 1
X7DL Blade lower guard 1 X7BN Lower door assembly 1
X7DK Saw body 1 X7BM Upper blade wheel assembly 1
X7DJ Block 1 X7BL Lower blade wheel assembly 1
X7DH Tension spring 1 X7BK Miter gauge assembly 1
X7DG Tension handle 1 X7BJ Lower blade guide support 1
X7DF Flat washer 4 X7BH
Lower bearing guide assembly 1
X7DE Hex nut 1 X7BG Work table assembly 1
X7DD Wing locking nut 1 X7BF Motor assembly 1
X7DC Blade wheel adjusting knob 1
