This tool is intended for use on a circuit that
has a receptacle like the one illustrated in
Fig. 1. Fig. 1 shows a three-pronged electrical
plug and receptacle that has a grounding
conductor. If a properly grounded receptacle
is not available, an adapter (Fig. 2) can be
used to temporarily connect this plug to
a two-contact grounded receptacle. The
adapter (Fig. 2) has a rigid lug extending from
it that MUST be connected to a permanent
earth ground, such as a properly grounded
receptacle box.
In all cases, make certain the receptacle
is properly grounded. If you are not sure,
have a qualied electrician check the
receptacle.
CAUTION
!
Fig. 1
Fig. 2
Three-Pronged Plug
Grounding Prong
Properly Grounded
Three-Pronged Receptacle
Grounding Lug
Make sure this
is connected to
a known ground.
Two-Pronged
Receptacle
Adapter
