Porter-Cable PXCMSAC420VW - Parts List

19 - ENG
REF. NO PART NO. KIT NO. DESCRIPTION QTY
1
E111986
Pump / Motor Assembly
1
2
E112321
Air Filter
2
3
Elbow 1/2 MNPT x 9/16 UNEF Comp
1
4
E111990
Outlet Tube Braided SS
1
5
E101208
Check Valve
1
6
E111988
Cushion Pad
1
7
Nut M6
4
8
E110785
Capacitor Cover
4
9
SCREW 1/4 - 20 X .75
2
10
E101800
Strain Relief
2
11
E110786
Capacitor 150uF
1
12
Rubber Gasket
1
13 2
Pressure Relief Tube
1
14 2
Nut 1/4
2
15
2 Ferrule 1/4
2
16
E102756
Pressure Switch 150PSI
1
17
E102612
Safety Valve
1
18
E101340
Power Cord
1
19
E101802
Strain Relief
1
20
E109688
Stand Pipe w/ Nipple / Nut Assy
1
21
Tank, Assy, 20 Gallon
1
22
E100240
Isolator, Foot (60mmDia X 28mm Tall)
2
23
Screw, HH M8 X 1.25 Self Tap
2
24
E107047
Drain Valve
1
25 1
Nut, Nylon M10 X 1.5 1.25
2
26 1
Washer Lock
2
27 1
Spacer, Wheel
2
28 1
Wheel, 7" X 1.5" Black (Gray)
2
29 1
Bolt, Shoulder M10 X 1.5 X 55mm
2
30 1
Cap, Wheel
2
31 Screw, SHC M8 x 1.25 x 16 mm ( ZDC Plate) 4
32
Washer, Lock 8 mm
4
33
Washer, Flat 8mm X 19 mm
4
34
Frame
1
35
Hanger Air Hose
1
36
E101951
Assy, Manifold / Regulator
1
37
Gauge, 38mm, 1/4 NPT
1
38
Elbow Male x Female 1/4NPT
1
39
Hose Manifold, 3/8" ID Rubber
1
40
Gauge, Pressure 50 mm 0-250 PSI w/ 150 Red Line
1
41
E103746
Quick Connect
2
42
Panel Manifold
1
43
Screw, Pan HD Washer M6 X 1 X16 mm
4
44
3 Plastite Screw #10-14x19 mm T20
2
45 3
Shroud Upper 1
46 3 Shroud Lower 1
NOTE: Any part number field without a number listed is not available.
PARTS LIST
47
Grip
1
4
4
4
4
E108321
E113451
E112259
E103686
E102362
E111989
E102822
