Luminaire is equipped with Portman Colour Feedback System. The navigation buttons under the OLED
screen are highlighted with RGB LEDs. The Portman CFS allows you to check the fixture status without
even touching the display or buttons. There are few possibilities:
Fixture receives DMX or WDMX signal
The fixture is in DMX operating mode, but there is no DMX nor WDMX signal detected
The fixture is in MASTER operating mode and there is no DMX signal detected
The fixture is in SLAVE mode and there is no DMX nor MASTER signal detected
The fixture is in SLAVE mode and there is MASTER signal detected. There is no DMX signal.
Portman Colour Feedback System works also when you operate the menu. When you navigate through the
menu the buttons change their colours. In the first level of the menu, the buttons are blue, the second level
of the menu is cyan. When you start editing a parameter in the menu the buttons turn red. Remember that
any changes will not be saved until you confirm them with the “ENTER” button. The changes are stored
only after you see the “You made it!” confirmation screen.
Sets up the DMX start address
Sets up the DMX mode. Refer to DMX chart for DMX
channels order.
Changes the DMX input to wired (default). In this mode,
the fixture is receiving a DMX signal from the DMX IN 5 pin
XLR socket.
Changes the DMX input to wireless. This mode works only
when the WDMX card is installed. Fixture is receiving DMX
data from the WDMX card.
Changes the fixture’s operating mode. Refer to the
Operation Modes chapter for more info. DMX is default
Changes dimming curve of filaments. Halogen mode is
emulating the behavior of halogen using also glow
sources. Logarithmic is the default.
Changes the frequency of the LED driving signals.
