System Overview
RUBY-D716VG2AR User’s Manual 1-3
z Power Requirements
Item Power ON
Full Loading
10Min
Full Loading
30Min
CPU +12V
1.07A 1.83A 2.10A
System +12V
0.93A 1.28A 1.40A
System +3.3V
0.69A 0.93A 1.01A
System +5V
1.20A 2.02A 1.97A
System+ Device +12V
2.42A 3.42A 3.96A
System+ Device +5V
2.22A 2.81A 2.89A
USB Loading Test
4.75~4.85V/ 580 mA
z Configuration:
SBC BIOS
Portwell, Inc. RUBY-D716VG2AR TEST BIOS
VGA Card
Intel Haswell HD Graphics –GT2
VGA Driver
Intel Haswell HD Graphics –GT2 Version:9.17.10.2895
LAN Card
Onboard Intel® I217-LM / I210 Gigabit Network Connection
LAN Driver
Intel® I217-LM/I210 Gigabit Network Connection
Version:12.5.19.0 /12.4.36.
Audio Card
On board Realtek ALC886 High Definition Audio
Audio Driver
Realtek ALC886 High Definition Audio Version :6.0.1.6662
Chip Driver
Intel® Chipset Device Software Version:9.4.0.1011
USB 3.0 Driver
Intel® USB3.0 eXtensible Host Controller Version:2.0.2.100
SATA HDD
Seagate ST3250312CS 250GB
Power Supply
FSP GROUP INC, FSP350-60GLC
z Operating Temperature
0 °C ~ 60 °C
z Storage temperature
-20 ~ 80 °C
z Relative Humidity
0% ~ 90%, non-condensing
