System Installation
RUBY-D716VG2AR User’s Manual 3-1
Chapter 3
System Installation
This chapter provides the instructions to set up the system. The additional
information is enclosed to help you set up onboard devices
3.1 Intel® Dual Core/Quad Core processor
LGA-1150 CPU Socket
Pin1 corner of the CPU Socket
LGA-1150 CPU
Yellow Triangle Pin1 of the CPU
Ali
g
nment ke
y
Notch
