Hardware Configuration
RUBY-D716VG2AR User’s Manual 2-1
Chapter 2
Hardware Configuration
This chapter indicates jumpers’, headers’ and connectors’ locations. Users may find useful
information related to hardware settings in this chapter.
2.1 Jumper Setting
For users to customize RUBY-D716VG2AR’s features. In the following sections, Short
means covering a jumper cap over jumper pins; Open or N/C (Not Connected) means
removing a jumper cap from jumper pins. Users can refer to Figure 1 for the Jumper
allocations.
Figure 1-1 RUBY-D716VG2AR Top View
