JP2: COM2 RI POWER Select
JP3: COM1 RI POWER Select
JP5: Clear CMOS
JP6: SATA Port Selection
PIN No.
Signal Description
1-3, Short
5V
3-4, Short
RI
3-5, Short
12V
PIN No.
Signal Description
1-3, Short
5V
3-4, Short
RI
3-5, Short
12V
PIN No.
Signal Description
1-2 Short
Normal Operation
2-3 Short
Clear CMOS Contents
PIN No.
Signal Description
1-2, Short
CFEX (J34)
1-2, Open
SATA Connector(J28)
