SW1: BIOS Boot Selection
4.3 Connector Settings
Connector Allocation
I/O peripheral devices are connected to the interface connectors
Connector Function List
Connector
Function
Remark
J1
HDMI Connector
J2
VGA + DVI Connector
J3
COM1 & 2 Connector
COM2(RS-232/422/485)
J4
SPDIF Pin HDR
J5
Audio Jack ( Mic + Line in + Line out )
J6
RJ45 + USB3.0 Connector
J7
RJ45 + USB3.0 Connector
J8
SMBUS Pin HDR
5x1 pin header
J9
+12V Power Connector
CPU Power
J10
PCIe x 4 Slot
Gen3
PIN No.
Signal Description
SW1_ON , SW2_OFF
Boot from SPI Flash
SW1_OFF , SW2_ON
Boot from CFEX
