2 Specifications
Main Processor
◆Intel® Kaby Lake / Sky Lake -S Core™ i Processors
System Chipset
◆Intel®Q170 or C236 Express chipset
System BIOS
◆AMI UEFI BIOS
Main Memory
◆Up to 64 GB in 4 slots 288-pin DIMM sockets. Supports dual channel DDR4 1866/2133 MHz SDRAM.
Graphics
◆Controller: Intel® Gfx Gen 9, HD graphics
◆VGA: Supports VGA up to resolution 1920 x 1200 @ 60Hz
◆DVI-D: Supports DVI-D up to resolution 1920 x 1200 @ 60Hz
◆HDMI: Supports HDMI up to resolution 4096 x 2304 @ 24Hz
◆Support Triple Display
Expansion Interface
◆One PCIe x16 slot (Gen 3.0 8GT/s)
◆Two PCIe x4 slot
◆Four PCI slots
SATA Interface
◆Up to eight SATA 6Gb/s ports (Q170 supports six SATA 6Gb/s ports)
◆One SATA 6Gb/s CFEX (switch with one SATA port)
Input/ Output
◆Serial Ports: Six serial ports, 5 x RS-232 & 1 x RS-232/422/485
◆Support PS/2 Keyboard and mouse connector (Pin Header)
◆USB Port: 6 x USB 3.0, 8 x USB 2.0
◆GPIO connector: 8-bit general purpose Input/ Output
◆Audio Interface: Connector for Mic-In, Line-In and Line-Out
