J11
PCIe x 4 Slot
Gen3
J12
Front Panel Pin HDR
J13
PCIe x 16 Slot
Gen3
J14
General Purpose I/O Pin HDR
J15
PS/2 KB & MS Pin HDR
J16/J17/J18/J19
Internal USB2.0 Pin HDR
J20
CPU FAN Power Connector
J21/J26/J27/J30
DDR4 Socket
J22
COM5 Connector
RS-232
J23
COM4 Connector
RS-232
J24
COM3 Connector
RS-232
J25
COM6 Connector
RS-232
J28/J29/J31/J32
J35/J36/J39/J40
SATA GEN3 Connector
J35 & J29 For C236 PCH
J33
Internal USB3.0 Pin HDR
J34
CFEX
J37
TPM
J38
ATX 24 Pin Power Connector
J41
System FAN Power Connector
PCI Slot1-4
PCI Slot
U36
BIOS EEPROM Socket
U24
EC EEPROM Socket
