RUBY-D718VG2AR
Copyright © Portwell 2016 RUBY-D718VG2AR User's Guide
Emulation: ANSI: Extended ASCII char set. VT100: ASCII char set. VT100+:
Extends VT100 to support color, function keys, etc. VT-UTF8: Uses UTF8
encoding to map Unicode chars onto 1 or more bytes.
VT100, VT100+, VT-UTF8, ★ANSI
Select Serial port transmission speed. The speed must be matched on other
side. Long or noisy lines may require lower speeds.
9600, 19200, 38400,57600,
★115200
A parity bit can be sent with the data bits to detect some transmission errors.
Even: parity bit is 0 if the num of 1‘s in the data bits is even.
Odd: parity bit is 0 if num of 1‘s in the data bits is odd. Mark: parity bit is always
1. Space parity bit is always 0. Mark and Space Parity do not allow for error
detection. They can be used as an additional data bit.
★None, Even, Odd, Mark, Space
Stop bits indicate the end of a serial data packet. (A start bit indicates the
beginning). The standard setting is 1 stop bit. Communication with slow devices
may require more than 1 stop bit.
Flow control can prevent data loss from buffer overflow. When sending data, if
the receiving buffers are full, a ‗stop‘ signal can be sent to stop the data flow.
Once the buffers are empty, a ‗start‘ signal can be sent to re-start the flow.
Hardware flow control uses two wires to send start/stop signals.
VT-UTFB Combo Key Support
Enable VT-UTF8 Combination Key Support for ANSI/VT100 terminals
With this mode enabled only text will be sent. This is to capture Terminal data.
