POSIFLEX PP-7600 - Loading a Paper Roll

5
Loading a Paper Roll
Before loading a paper roll, make sure you use a specified paper type. Follow
the steps below to load a paper roll.
1. Press down the cover open lever to
release the paper cover.
2. The paper cover ejects. Then, open the
paper cover manually.
3. Drop the 80mm-wide thermal paper
inside the paper compartment of the
printer, as shown in the right figure.
4. Drag the paper roll to the portion where
the paper roller is installed.
Paper Roller
