POSITECTOR 6000 User Manual

1
Introduction
Introduction
The PosiTector 6000 hand-held, electronic Gage
non-destructively measures the thickness of coatings on all metals,
quickly and accurately. It consists of a Gage body
(Standard or Advanced) and probe (Built-In or Separate).
PosiTector 6000 Kit Contents
- PosiTector 6000 Probe
- Protective rubber holster with belt clip
- Protective Cap for Probe (some probes only)
- Protective Lens Shield
- Wrist strap
- 3 Alkaline AAA batteries
- Quick Guide Instructions
- Nylon carrying case with shoulder strap
- USB Cable
- Precision Plastic Shims
- Certificate of Calibration traceable to NIST
- Two (2) year warranty on Body and Probe
Principles of Operation
F probes use the magnetic principle to measure the thickness of
non-magnetic coatings on ferrous metals.
N probes use the eddy current principle to measure the thickness of
non-conductive coatings on non-ferrous metals.
FN probes combine the full abilities of both the "F" and "N" probes.
Quick Start
Quick Start
The PosiTector 6000 powers-up when the center navigation button is
pressed. To preserve battery life, it powers-down after approximately
5 minutes of no activity. All settings are retained.
1. Remove the protective plastic cap (if supplied) from probe.
2. Power-up Gage by pressing the center navigation button.
3. Place the probe FLAT on the surface to be measured.
HOLD STEADY. When a valid measurement is calculated, the Gage
BEEPS twice and the measurement is displayed.
4. Lift probe AT LEAST 2 INCHES (5cm) from the surface between
measurements - OR - leave probe on the surface in the same
location for continuous measurements.

POSITECTOR 6000 Specifications

General

Measurement Principle	Eddy Current
Operating Temperature	-4 °F to +122 °F (-20 °C to +50 °C)
Data Storage	Up to 1000 readings
Connectivity	USB
Languages	English, Spanish, French, German, Portuguese, Russian, Chinese
Dimensions	165 x 64 x 31 mm (6.5" x 2.5" x 1.2")
Display	Backlit LCD
