Positron G1002-C User Manual

G1002-C Quick Installation Guide
Positron Access Solutions 10 Document 180-0219-001 R01
______________________________________
Technical and Regulatory Specifications
G1002-C Technical Specifications
Environmental Features
Dimensions
3.7” Width x 1.35” Height x 6.7” Depth / 95 mm W x 34.3 mm H x 169.5 mm D
Power
12 VDC / 1A power adapter (110-220VAC), 4.8 W maximum
Certification
CE Mark, FCC Part 15 Class B
Temperature
Operating: 0˚C to +40 ˚C / Storage: -25˚C to +80 ˚C
Operating Humidity
5% to 95% relative, non-condensing
G.hn Specification
G.hn Standards
G.hn Wave-2 Client, based on GigaWire Alliance specification and fully
compliant with the following ITU-T standards
• G.9960 Amendment 2 - System Architecture and PHY Layer
• G.9961 Data Link Layer
• G.9962 Management
• G.9964 PSD
Ease of Deployment
Support G.hn over coax (G1002-C)
Point-to-point and Point-
to-multipoint support
Supports Point-to-point or Point-to-multipoint operation (coax) for up to
16 G1002-C per G.hn port
Ease of Operation
Automatic firmware and configuration management via the Positron GAM
Encryption
AES-128 encryption with individual keys for each end-node under the control of
the Positron GAM acting as the Master Node
Modulation and
Frequency Band
Band Notching function allows cohabitation with legacy Analog Cable TV
channels over coax
Bandwidth Management
Up to 1.7 Gbps with Dynamic Bandwidth Allocation to optimize throughput
based on nature of traffic flows with TDD Multiplexing for programmable
upstream / downstream ratio
Reliability and Resiliency
State of the art LDPC Forward Error Correction (FEC)
Table 3: G1002-C Summary Specification

Positron G1002-C Specifications

General

Brand	Positron
Model	G1002-C
Category	Network Router
Language	English
