Postek G-3106 - Chapter 1: Introduction; Specifications

G-2108/G-3106 User’s Manual Chapter 1: Introduction
4
Chapter 1: Introduction
1.1 Specifications
Model by Resolution
203DPI
300DPI
Printing Mode
Direct Thermal & Thermal Transfer
Max Printing Speed
6ips (152.4 mm/s)
5ips (127 mm/s)
Max Printing Width
4.25″ (108 mm)
4.17″ (106 mm)
Max Printing Length
315″ (8000 mm)
157″ (4000 mm)
HEAT
TM
Level
I
I
Memory
64 MB FLASH ROM, 16 MB SDRAM
Media
Width: 4.4″ (112 mm) max., 0.98″ (25 mm) min.
OD: 6″ (152 mm) max.
ID: 1″ (25.4 mm) min.
Media Thickness
0.003″ ~ 0.008″ (0.08 ~ 0.20 mm), including liner
Ribbon
Width: 4.3″ (110 mm) max.
Length: 984' (300 m) max.
OD: 2.75″ (70 mm) max.
ID: 1″ (25.4 mm) min.
Media Sensor
Reflective (Adjustable) / Transmissive (Two positions)
Fonts
Five built-in dot matrix ASCII fonts, user-downloadable TrueType Fonts
Barcode Types
1D Barcode: Code 39, Code 93, Code 128/subset A,B,C, Codabar,
Interleave 2 of 5, UPC A/E 2 and 5 add-on, EAN-13/8/128, UCC-128, etc.
2D Barcode: MaxiCode, PDF417, Data Matrix, QR Code, etc.
Interfaces
RS-232 Serial, 10/100 M Adaptive Ethernet, USB DEVICE 2.0
Power Adapter
Input: AC 100~240 V, 50~60 Hz
Output: DC 24 V, 2.5 A
Weight
7.72lbs (3.5 kgs)
Dimensions
W 10.2″ (259mm) x D 13.9″ (354mm) x H 8.1″ (205 mm)
Operating
Environment
Temperature: 32 F ~ +104 F (0 C ~ 40 C)
Relative humidity: 5% - 85% non condensing
Storage Environment
Temperature: -40 F ~ +140 F (-40 C ~ 60 C)
Relative humidity: 5% - 85% non condensing
Optional Items
Centronics Parallel Port*
Cutter, External Label Rewinder, External Media Stand, Media Guide
Adapter
HEAT
TM
, or Heating Equilibrium Adaptive Tuning, is a POSTEK designed and developed
cutting-edge technology that sets the benchmark for heat management in thermal printing. Printers
equipped with HEAT
TM
have significant improvements in their printout clarity and print speed. The
HEAT
TM
level represents the fineness of the heating uniformity with level I being the finest.
*Factory dependent.
