Configuration Prog. no. Level Standard value
Function input H1
0: {None | 1: Optg mode change HCs+DHW | 2: Optg mode changeover DHW |
3: Optg mode changeover HCs | 4: Optg mode changeover HC1 | 5: Optg mode
changeover HC2 | 6: Optg mode changeover HC3 | 7: Heat generation lock | 8:
Error/alarm message | 9: Consumer request VK1 | 10: Consumer request VK2 |
11: Release swi pool source heat | 12: Excess heat discharge | 13: Release swi
pool solar | 14: Operating level DHW | 15: Operating level HC1 | 16: Operating
level HC2 | 17: Operating level HC3 | 18: Room thermostat HC1 | 19: Room
thermostat HC2 | 20: Room thermostat HC3 | 22: DHW thermostat | 24: Pulse
count | 28: Checkb sign flue gas damper| 29: Start prevention | 51: Consumer
request VK1 10V | 52: Consumer request VK2 10V | 58: Output request 10V |
60: Temp measurement 10V
5950 C None
Contact type H1
NC | NO
5951 C NO
Voltage value 1 H1 5953 E 0
Function value 1 H1 5954 E 0
Voltage value 2 H1 5955 E 10
Function value 2 H1 5956 E 1000
Function input H4
0: None | 1: Optg mode change HCs+DHW | 2: Optg mode changeover DHW |
3: Optg mode changeover HCs | 4: Optg mode changeover HC1 | 5: Optg mode
changeover HC2 | 6: Optg mode changeover HC3 | 7: Heat generation lock | 8:
Error/alarm message | 9: Consumer request VK1 | 10: Consumer request VK2 |
11: Release swi pool source heat | 12: Excess heat discharge | 13: Release swi
pool solar | 14: Operating level DHW | 15: Operating level HC1 | 16: Operating
level HC2 | 17: Operating level HC3 | 18: Room thermostat HC1 | 19: Room
thermostat HC2 | 20: Room thermostat HC3 | 22: DHW thermostat | 24: Pulse
count | 28: Checkb sign flue gas damper | 29: Start prevention | 50: Flow
measurement Hz
5970 C None
Contact type H4
0: NC | 1: NO
5971 C NO
Frequency value 1 H4 5973 E 0
Function value 1 H4 5974 E 0
Frequency value 2 H4 5975 E 0
Function value 2 H4 5976 E 0
Function input H5
0: None | 1: Optg mode change HCs+DHW | 2: Optg mode changeover DHW |
3: Optg mode changeover HCs | 4: Optg mode changeover HC1 | 5: Optg mode
changeover HC2 | 6: Optg mode changeover HC3 | 7: Heat generation lock | 8:
Error/alarm message | 9: Consumer request VK1 | 10: Consumer request VK2 |
11: Release swi pool source heat | 12: Excess heat discharge | 13: Release swi
pool solar | 14: Operating level DHW | 15: Operating level HC1 | 16: Operating
level HC2 | 17: Operating level HC3 | 18: Room thermostat HC1 | 19: Room
thermostat HC2 | 20: Room thermostat HC3 | 22: DHW thermostat | 24: Pulse
count | 28: Checkb sign flue gas damper
5977 C None
Contact type H5
0: NC | 1: NO
5978 C NO
Function output P1
0: None | 1: Boiler pump Q1 | 2: DHW pump Q3 | 3: DHW interm circ pump Q33
| 4: Heat circuit pump HC1 Q2 | 5: Heat circuit pump HC2 Q6 | 6: Heat circuit
pump HC3 Q20 | 7: Collector pump Q5 | 8: Solar pump ext exch K9 | 9: Solar
pump buffer K8 | 10: Solar pump swi pool K18
6085 E Heat circuit pump
HC1 Q2None
Signal logic output P1
0: Standard | 1: Inverted
6086 E Inverted
Sensor type collector
1: NTC | 2: Pt 1000
6097 E NTC
Readjustm collector sensor 6098 E 0 °C
Readjustm outside sensor 6100 E 0.0 °C
Time constant building 6110 C 10 h
Central setp compensation 6117 E 10 °C
9 Settings
72 Paramount five 30 – 115 7703046 - 01 - 23072018
