Fig.13 Connection possibilities with KAS (accessory)
C
33 (3)
C
13
RA-0000311
C
33 (1)
C
33 (1)
C
93 (2)
B
23
B
23
C
33 (1)
C
33 (3)
6.4.3 Permissible flue gas pipe lengths
Paramount 28 / 38 50 / 60 70 90 110
Flue Type Flue
Size
Max
Flue
Leng
th
(1)
Max.
No of
Bend
s
(90°)
Flue
Size
Max
Flue
Leng
th
(1)
Max.
No of
Bend
s
(90°)
Flue
Size
Max
Flue
Leng
th
(1)
Max.
No of
Bend
s
(90°)
Flue
Size
Max
Flue
Leng
th
(1)
Max.
No of
Bend
s
(90°)
Flue
Size
Max
Flue
Leng
th
(1)
Max.
No of
Bend
s
(90°)
C13 (Concentric
Vertical)
80/1
25
10(5) 2 110/
150
5(5) 2 110/
150
5(5) 2 110/
160
5(5) 2 110/
160
5(5) 2
C33(1) (Concentric
Vertical)
80/1
25
13 0 110/
180
22 0 110/
180
13 0 110/
180
10(3) 0 110/
180
10(3) 0
C33(1) (Concentric
Vertical)
110/
160
(2)
20 0 120/
180
(2)
20 0 120/
180
(2)
C93(2) (Concentric
Vertical)
80/1
25
15(3) 2 110/
180
24(3) 2 110/
180
15(3) 2 110/
180
18(3) 2 110/
180
20(3) 2
C33(3) (Concentric
Vertical)
80/1
25
7(3) 2 110/
180
13(2) 2 110/
180
9(3) 2 110/
180
110/
180
B23 (Conventional
Flue)
(2)
80 20(3) 3 110 25(3) 3 110 16(3) 3 110 20(3) 2 110 20(3) 2
(1) This is the maximum flue length, the allowable horizontal run within total flue length is shown in brackets.
(2) not supplied byPotterton Commercial
See
Flue sizes shown for the Concentric Vertical Flue are adapted
sizes for flues supplied by Potterton Commercial. For flues
supplied by other manufactors, please refer to technical data for
standard spigot sizes.
