Power Acoustik PD-710B - 99-6501 Kit Assembly - ISO DIN; ISO DIN Radio Provision Installation

Chrysler Sebring/Dodge
Avenger 1995-2000, Jeep Grand
Cherokee 1993-1995
1. Cut and remove all mounting tabs
on the Radio Housing EXCEPT the
shaded tabs.
Continue to kit assembly, p. 3.2-3
1. Cut and remove all mounting tabs
on the Radio Housing EXCEPT the
shaded tabs.
Continue to kit assembly, p. 3.2-3
Ford/Lincoln/Mercury
1979-1989
3.2
Kit Preparation 99-6501 Kit Assembly 99-6501
(Figure A)
ISO DIN radio provision
1. Snap the ISO DIN faceplate into the radio housing and then slide the
aftermarket radio into the back of the kit.
2.
Slide the ISO DIN brackets onto the housing legs and align the holes in the
brackets with the holes in the unit.
3.
Mount the brackets to the unit with (4) 5mm Flat-head screws supplied (“A”).
(Figure A)
“A”
“A”
“B”
“B”
