Power Acoustik PD-710B - Dash Disassembly Procedures INST-6000 - Continued; Lincoln Continental (1985-1987) Dash Disassembly; Lincoln Mark VII (1984-1989) Dash Disassembly

INST-6000
Notes
1. Pry out on the dash
trim bezel and remove.
(Figure A)
2. Remove (4) 5mm
hex-head sheet metal
screws securing the
factory radio and
disconnect the wiring.
Lincoln Mark VII
1984-1989
Lincoln Continental
1985-1987
1. Remove (2) #8 Phillips
screws below the
radio opening.
2. Open the ashtray and
remove (2) #8 Phillips
screws (it is NOT
necessary to remove
the center screw).
3. Unclip the dash trim
bezel and remove.
4.
Remove (4) hex-head screws securing the factory
radio and disconnect the wiring.
6.9
Dash Disassembly INST-6000
