Power Acoustik PD-710B - Dash Disassembly Procedures INST-6000 - Continued; Dodge Omni;024;Rampage;Plymouth Horizon;TC3;Scamp Dash Disassembly; Dodge Pickup;Ramcharger;Plymouth Trailduster (1974-1980) Dash Disassembly

6.6
Dash Disassembly INST-6000
1.
Remove (7) Phillips
screws from the dash
trim bezel and remove
the bezel.
2. Remove (2) 3/8”
hex-head screws
securing the factory
radio and disconnect
the wiring.
Dodge Omni/024/Rampage
1978-1982, Plymouth
Horizon/TC3 1978-1982/
Scamp 1983-1984
1. Remove (5) Phillips
screws from the edge
of the dash trim bezel.
2. Remove (1) Phillips
screw above the
radio opening.
3. Pry out on the
bottom edge of the
bezel and remove.
4. Remove (2) 3/8”
hex-head screws
Dodge Pickup/Ramcharger
1981-1993, Plymouth
Trailduster 1981
4. Unclip the bezel
and remove. (Figure A)
5. Remove (2) 3/8”
hex-head screws
securing the factory
radio and disconnect
the wiring.
Dodge Pickup/Ramcharger
1974-1980, Plymouth
Trailduster 1974-1980
1. Remove (4) Phillips screws from the top edge of
the dash trim bezel.
2. Remove (7) Phillips screws from the face of the
dash trim bezel.
3. Remove (3) Phillips screws under the dash
trim bezel.
Dodge Pickup/Ramcharger
1974-1980, Plymouth
Trailduster 1974-1980
securing the factory
radio and disconnect
the wiring.
1. Remove the ashtray. Remove (2) Phillips screws
exposed in the ashtray cavity and remove the
ashtray bracket. Remove the cupholder.
2.
Remove (2) Phillips screws exposed
in the cupholder cavity and remove the
cupholder bracket.
3.
Unclip the dash trim bezel, pull the bezel over the
steering column and remove.
4.
Remove (2) 3/8” hex-head screws securing the
factory radio and disconnect the wiring.
Dodge Ram 1994-2001,
Ram 2500/3500 2002
