6.3
Dash Disassembly INST-6000
1. Remove (4) Phillips screws from the top of the
dash trim bezel.
2.
Remove (4) Phillips screws from the bottom of the
dash trim bezel.
3.
Remove (2) 3/8” hex-head screws securing the
factory radio and disconnect the wiring.
Chrysler LeBaron 1976-
1981, Dodge Diplomat
1976-1989/Aspen
1976-1980, Plymouth Gran
Fury 1975-1985/Volare
1976-1980
1. Unclip the radio trim
bezel and remove.
2.
Remove (2) 3/8”
hex-head screws
securing the factory
radio and disconnect
the wiring.
Chrysler Sebring (convertible)
1995-2000
1. Unclip the radio trim
bezel and remove.
2.
Remove (2) #10
Phillips screws
securing the factory
radio and disconnect
the wiring.
Chrysler Sebring/Dodge
Avenger 1995-2000
1. Remove (5) torx-head screws from the top of the
dash trim bezel.
2. Remove (2) torx-head screws below the radio
opening.
3. Remove (1) torx-head screw from the upper-left
corner of the radio opening.
4. Remove (4) torx-head screws from the lower-left
area of the dash trim bezel.
5. Unclip the bezel and remove.
6. Remove (2) 3/8” hex-head bolts securing the
factory radio and disconnect the wiring.
Chrysler LeBaron GTS
1985-1994, Dodge Lancer
1985-1989
