- 19 -
FIG. 9 4CHANNEL TRI MODE CONFIGURATION
STAX 1200/4, STAX 1600/4, STAX 2300/4
1CH
4-8 Ohms
WOOFER
2CH
4-8 Ohms
3CH
4-8 Ohms
4CH
4-8 Ohms
WOOFER
1.Lowest Recommended Impedance is 4ohm Stereo
2.RCA Inputs are connected to both Left and Right channels
3.Output configured for stereo operation
