INSTALLING HOIST TO PLATFORM
CAUTION
NOTE
• The voltage loss for 100ft (30.48m) of 10/3
electrical cable is 2 volts for each hoist used.
If startup is sluggish, determine the voltage at the
motors when running. UP is between 198- 242 VAC.
If the voltage is lower than 198 VAC when running:
• Increase voltage with a transformer at the power
source when voltage is low OR,
• Use larger gauge or separate electrical cables to
each hoist to improve voltage supply.
• Do not start both hoists at the same time to insure
better hoist performance. Always maintain a level
platform.
The electric supply must have sufcient
capacity, and the circuit breakers must be properly
rated.
= Inspect
= Verify
=Perform process
Optional
pendant
connection
