EZ Diagnostic Mode – Scroll the Menu down using the Left
Button until EZ DIAGNOSTICS is highlighted on the menu. Se-
lect EZ DIAGNOSTICS by pressing the Right Button. EZ DIAG-
NOSTICS are preset test modes for dierent vehicle system
tests.
The available tests listed are: Battery Check, Charge Test,
Fuse Test, Voltage Test, Component Test, 5V Ref.
Each test section includes a readable QR code that will ac-
cess online video content explaining the test procedure.
5V REF mode is used together with the Power Probe Tek 5V
Adapter Tip (# PPT5VA). With the Adapter Tip installed on the
probe and applying power, the probe will no longer output full
battery voltage. The 5 Volt Adapter will only output a current
limited 5V that can be used as a reference voltage to safely
power and test sensor and computer circuits.
FOR FULL EXPLANATIONS OF EACH TESTING MODE AND
SCREEN PLEASE GO TO:
www.powerprobetek.com/ezdiagnostics/ or scan the below
QR code:
WWW.POWERPROBETEK.COM
8
EZ DIAGNOSTICS
