Power Probe Basic
7
POLARITY TESTING
By contacting the Power Probe tip to a POSITIVE (+), circuit will light
the LED indicator RED.
By contacting the Power Probe tip to a NEGATIVE (-), circuit will
light the LED indicator GREEN.
By contacting the Power Probe tip to an OPEN, circuit will be indi-
cated by the LED indicator not lighting.
Red LED = Positive
Green LED = Negative
6 -12 VOLTS
BATTERY
BATTERY
6 -12 VOLTS
