2) Product specification
Ratings
Operating environment
Voltage, V
400, 3-phase
Service condition
Outdoor use
Frequency, Hz
50
Ambient temperature
-10°C to 50°C
Load steps, kW
5, 10, 15, 20, 50, 100
Humidity
95% RH
Total capacity, kW
200
Ingress protection
IP23 Load enclosure
IP54 Control
compartment
Control and ventilation
Construction
Manual controls
System on/off pushbuttons,
supply rotary selector
switch, emergency stop
Resistor elements
Stamped grid and wire
coils
Control interface
7” touch screen display
Element material
Stainless steel
Cooling
Forced convection,
horizontal orientation
Enclosure
Dual layer; galvanized
sheet steel, painted
RAL9002 grey
Fan(s)
1 x 2.7kW fan, axial type
Manoeuvrability
4 x heavy duty castors,
forklift pockets.
Control supply
400V 3-phase, 3-wire AC
Source
Internal (supply under test)
or external supply
(recommended)
Weight and dimensions
Drawing reference
164043
Connection interfaces
Length, mm
1175
Load connections
5 x Powersafe sockets
(3P+ N + PE)
Width, mm
806
Control supply
1 x EN 60309 3P+PE 16A
Height, mm
1370
Data downloads
USB Type-A
Weight, kg
240
Networking/remote
2 x RJ45
Safety
Electrical protection
Over current and short
circuit fuse protection
Over voltage protection
(via control system)
Thermal protection
PT100 monitoring (load
and control compartments)
PT100 healthy status
Airflow status
