17
CHANGING THROW DIRECTION AND THROW HEIGHT
2. The chute deflector (G) on the top of the discharge
chute (H) controls the height of the snow stream.
Loosen both chute deflector knobs to raise or lower
the deflector to the desired height you wish to throw
the snow. Tighten the knobs to secure the deflector.
Note: Do not overtighten the chute deflector knobs.
2
Never direct the snow discharge chute at the operator, at bystanders, at vehicles or at nearby
windows. Discharged snow and foreign objects accidentally picked up by the snow thrower can
cause serious damage and personal injury.
Always orient the discharge chute in the opposite direction from where you, bystanders, surrounding
vehicles, or windows are located.
OPERATING INSTRUCTIONS
WARNING
1. The discharge chute (H) can be adjusted 180 degrees
by rotating the chute crank. Rotate the chute control
crank clockwise to move the discharge chute (H) to the
left, counterclockwise to move the chute to the right.
1
H
G
H
