Page 12 of 41
SPECIFICATIONS
ENGINE
Make Kubota
Model V1505
Cylinders 4
Aspiration Natural Aspiration
EPA Tier Tier 4
HP @ 1800rpm (Continuous Duty) 18.0
Approximate Fuel Consumption
0.47 gal/hr @ ½ Load
1.1 gal/hr @ Full Load
Starting Voltage 12VDC
Battery Cable Gauge 2 AWG Minimum
Oil Capacity Approx. 4.5 Qts (4.3 L)
Cooling System Capacity Approx. 6.5 Qts (6.1 L)
GENERATOR
Generator Type
Brushless with Automatic Voltage
Regulator
Generator Output
(Continuous Prime)
PT-10KSIC
10000W @ 60Hz
8300W @ 50Hz (Optional)
PT-12KSIC
12000W @ 60Hz
10000W @ 50Hz (Optional)
MAINTENANCE PARTS
Replacement Air Filter Element 04FA221
Replacement Primary Fuel Filter 08FF17
Replacement Inline Fuel Filter 08FFG17B
Replacement Oil Filter 01FO05S
These and other additional parts available at powertechgenerators.com.
