Modes
The following table describes the different operating modes of the controller:
Mode / State Description
OFF When in the OFF mode, the generator set is shutdown and cannot be
remotely started. The generator set can be started manually from the
local controller.
AUTO When in the AUTO mode, the controller waits to receive an external
start signal from a remote panel, transfer switch or other device.
RUNNING When the generator set is running, the controller monitors engine &
generator parameters and waits to receive a stop command.
FAILURE When a failure occurs, the controller shuts down the generator set and
displays the reason for failure. The controller must be reset using the
OFF button on the local controller. The controller cannot be reset or
started from a remote source.
CONTROLLER OPERATION
Viewing Parameters
Various engine and generator parameters can be viewed on the LCD Display. The parameters will
automatically scroll, but by pressing the UP or DOWN buttons you can scroll through to the information
you want to see. Once on the information desired, press the ENTER button to lock the screen and
prevent it from automatically scrolling. A lock icon will appear to signify that the display is locked. Press
the ENTER button again to unlock it. What parameters are displayed depends on what mode the
controller is in. If a parameter is highlighted, that indicates the parameter is outside the acceptable range
and either a warning or fault will be displayed as well.
In OFF mode, no parameters are available.
In AUTO mode, the following parameters are available:
Battery Voltage
Engine Temperature
Oil Pressure
Engine Hours
While running, the following parameters are available:
Battery Voltage
Engine Temperature
