Page 25 of 41
1. Shut down the generator set and put it in OFF mode.
2. Ensure the generator set is on a level surface. If the generator set is on a grade, the oil level
measurement may be incorrect.
3. Allow the generator set to sit for at least 5 minutes to allow the generator set to cool and allow oil
to flow back to the oil pan.
4. Remove the dip stick, wipe it clean, and replace it.
5. Remove the dip stick again and observe the oil level. The oil should be between the ADD &
FULL marks.
6. If necessary, remove the oil cap and add new oil to bring the oil up to the correct level.
7. Replace the dip stick and oil fill cap, if removed.
Changing the Engine Oil and Filter
Moving Parts.
Will cause severe injury or death.
During operation, some parts of the generator set can become extremely hot. To avoid
burns, allow the engine to cool sufficiently before changing the engine oil.
Always stop the engine before changing the engine oil. DO NOT change the engine oil
while the engine is running.
Always put the generator set in OFF mode before changing the oil. If the generator set is in
AUTO mode, the generator set may start automatically, without warning.
1. Shut down the generator set and put it in OFF mode.
2. Ensure the generator set is on a level surface and properly supported.
3. Allow the generator set to sit for at least 5 minutes to allow the generator set to cool and allow oil
to flow back to the oil pan.
4. Drain the oil using one of the following methods:
o Using the oil drain plug
Remove the oil drain plug from the bottom of the oil pan and drain old oil into an
appropriate container.
Reinstall the oil drain plug.
o Using the oil drain valve
Install a 3/8” hose over the nipple on the end of the drain valve and route hose
out the bottom of the enclosure into an appropriate container.
Lift the lever and rotate it towards the nipple.
Hot Engine and Exhaust System
Can cause severe injury or death.
