28
Maintenance
List of wearable parts
Description Models or specifications
Spark plug LD L8RTF/902700
Chain bar 160SDEA041
Saw chain 91PJ057X
Maintenance after each use
WARNING! Before cleaning, inspecting or repairing your
unit, make sure that the engine has stopped and is cool.
Disconnect the spark plug to prevent accidental starting.
1. Air filter
Dust on the air filter surface can be removed by detaching the air
filter cover (A), removing the filter, and tapping a corner of the filter
cover (B) against a hard surface. To clean dirt in the meshes, brush
in petrol. When using compressed air, blow from the inside.
2. Oiling port
Detach the chain bar and check the oiling port (A) for clogging.
A
B
A
