-08-
3.5. Basic settings
The PowerBox Cockpit / Competition SRS feature a new kind of
graphic OLED screen, intended to do away with old-fashioned
programming methods based on flashing LED codes, morse code
beeps or obsolete mechanical jumpers. The screen provides the basis
for an extremely user-friendly control system, and eliminates the need
for a supplementary setup unit or programming device. The
SensorSwitch is employed as a convenient means of entering settings
within the menu system, and since the SensorSwitch is always used as
the main ON / OFF switch, it is always installed in the model, so you
cannot forget it. Wherever possible the screen provides full information
in English; few abbreviations are used. The overall result is an intuitive
method of programming which is a great advantage at the flying field, as
you will rarely need to consult the operating instructions.
This is the basic rule in programming: buttons I and II are used to
move the cursor or change values, while the SET button is used to
select or confirm your inputs.
The breadth of functions offered by the PowerBox Cockpit /
Competition SRS is enormous, but the unit is by no means difficult to
operate. To provide a clear idea of the sequence required in order to use
the backer, we have drawn up a brief list of operations
1. Battery setting Point 3.6
2. Setting the receiving system Point 3.7
4. Output mapping and Failsafe Point 3.8
5. Servo matching and door sequencer Points 4 and 5
6. Fail-Safe settings Point 3.9
3.6. Battery settings
These settings should always be entered first, so that you have an
accurate view of the state of the battery while you carry out further
adjustments. In the screenshot below you will see the default settings of
the PowerBox Cockpit / Competition SRS. If you wish to change
them, this is the procedure:
