Bluetooth: Built-in Bluetooth LE 4.0,
Nordic Semiconductor chipset.
Electro-compatibility (EMC): ETSI EN
301 489-1/EN 301 489-17/EN 50385/EN
55011/EN/IEC 60601-1-2.
C RF Data:
• Operating Frequency Range: 2402 MHz-
2480 MHz (ISM range).
• Modulation Type: GFSK with AFH.
• Peak Transmit Power: -15.86dBm (0.026
mW).
• Channel Spacing/Number of Channels: 2
MHz, 40 channels (3 for advertising, 37
for data).
• Antenna Type: Multilayer Chip Antenna, 2
dBi (1.58 mW) gain.
Mobile Application Compatibility:
• Android 5.0 Lollipop (or later) powered
smart phone with Bluetooth Smart Ready
compatibility and HD (or better)
• touch screen.
• Apple iPhone 5 or newer smart phone
powered by iOS 8.0 (or later).
TECHNICAL
SPECIFICATIONS
All electrical specifications are given for
an impedance of 1000 Ω per channel.
Battery: Lithium Polymer (LiPo)
rechargeable 3.7 V, 210 mAh (~5-6 hours
of continuous stimulation on average
parameters).
Charging Input: 5V through USB 2.0 or
3.0 connection (custom micro-USB to
USB charging cable is provided as part
of the package), I/P rating: 5Vdc 1-2.1A.
Stimulation Channels: 2 independent,
optically isolated.
Stimulation Waveform: Biphasic
symmetrical rectangular with zero mean.
Supported Stimulation Frequency
Range: 1-120 Hz.
Supported Stimulation Pulse Width:
160-416 μS (for main/positive phase).
Maximum output voltage/amperage:
125 V/125 mA (+/- 5%).
Housing: ABS & TPU.
Limitations: product is not suitable
for use in the environments with a
high concentration of oxygen and/or
flammable liquids and/or flammable gas;
do not use with equipment for electro
surgery or short-wave or microwave
therapy; the device may be interfered
by other equipment, even if that
other equipment complies with CISPR
EMISSION requirements.
Device Dimensions: 60.4x43.5x13.6 mm.
Device Weight: 25 g.
Environment Specifications:
• Operating/Storage/Transport:
Temperature from 0 C to +40 C.
• Humidity: 10-90% RH.
• Atmospheric pressure: from 700 hPa to
1060 hPa.
Product Expected Lifetime: 5 years.
PowerDot PD-01M has been tested to the compliance with the following Emission and
Immunity standards:
EMISSION:
Standard Item Remarks
CISPR 11: 2011 Conducted Class B
Radiated Class B
IEC 61000-3-2:2014 Harmonic current emissions
IEC 61000-3-3:2013 Voltage fluctuations & flicker
