PowerDot Uno - Page 30

58
59
IMMUNITY:
Standard Item
IEC 60601-1-2
Test Levels for Home
Healthcare Environment
PowerDot
PD-01M
Test Levels
Remarks
IEC 61000-4-
2:2008
ESD
± 8 kV contact;
± 2 kV, ± 4 kV,
± 8 kV, ± 15 kV air
± 2 kV,
± 4 kV, ± 8 kV
contact;
± 2 kV,± 4 kV,
± 8 kV,
± 15 kV air
No
performance
degradation
observed.
IEC
61000-4-3:2010
RS
10 V/m
80 MHz – 2.7 GHz
80% AM at
1 kHz
10 V/m
80 MHz –
5.785 GHz
80% AM at
1 kHz
No
performance
degradation
observed.
IEC
61000-4-4:2012
EFT
± 2 kV
100 kHz
repetition frequency
± 2 kV
100 kHz
repetition
frequency
No
performance
degradation
observed.
IEC
61000-4-5:2014
Surge
± 0.5 kV,
± 1 kV
± 0.5 kV,
± 1 kV
No
performance
degradation
observed.
IEC
61000-4-6:2013
CS
3V 0.15 MHz –
80 MHz
6V in ISM
and amateur bands
between 0.15 MHz and
80 MHz
80% AM at 1 kHz
10V
0.15 MHz – 80
MHz
80% AM at
1 kHz
No
performance
degradation
observed.
IEC
61000-4-8:2009
PFMF
30 A/m
50 Hz or
60 Hz
± 0.5 kV,
± 1 kV
No
performance
degradation
observed.
IEC
61000-4-
11:2004
Voltage
dips &
voltage
variations
Voltage Dips:
1) 0% UT; 0,5
cycle at 0º.
45º, 90º, 135º,
225º, 270º,
315º
2) 0% UT;
1 cycle;
Single phase at 0º
3) 70% UT;
25/30 cycles;
Single phase at 0º
Voltage
Interruptions:
0% UT;
250/300
cycle;
As on the
previous
column
Voltage Dips:
1) No performance
degradation
observed.
2) No performance
degradation
observed.
3) No performance
degradation
observed.
Voltage
Interruptions:
Performance
degradation
(device stopped
charging) has been
observed only
during voltage
interruption
testing, but no
degradation
observed after
the testing.
