POWERFIX PDM 250 A2
English - 7
Resistance
Range Resolution Precision
200Ω 0.1Ω ± (1.0%+5)
2kΩ 1Ω
± (0.8%+3)
20kΩ 10Ω
200kΩ 0.1kΩ
2MΩ 1kΩ
20MΩ 10kΩ ± (1.2%+3)
Overload protection: 250V
Battery test
Range Consumption
1.5V ±20mA
9V ±5mA
The specified precision in ± (% of the display + number of digits) is guaranteed for a period of
one year at an ambient temperature from 18°C to 28°C and maximum air humidity of 75%.
Safety instructions
Before using this multimeter for the first time, always read the following instructions and pay
attention to all warnings, even if you are familiar with handling electronic devices. Store these
instructions in a safe place for future reference. If you sell the multimeter or pass it on, always
include these instructions.
WARNING! This symbol indicates important information for safe
operation of the multimeter and the safety of the user.
This symbol indicates other important information on the topic.
