PowerMax PM - Page 25

PowerMax Pool Heater
Page 25
Model Model Model Model Model Model Model
Item Description 500 750 1000 1250 1500 1750 2000 66 Ignition Control E2107300 E2107300 E2107300 E2107300 E2107300 E2107300 E2107300
(1) (1) (1) (2) (2) (2) (2)
67 Diagnostic Board E2105500 E2105500 E2105500 E2105500 E2105500 E2105500 E2105500 68 Indicator Light Panel Board E2105600 E2105600 E2105600 E2105600 E2105600 E2105600 E2105600 69 Temperature Control E2317300 E2317300 E2317300 E2317300 E2317300 E2317300 E2317300 70 High Limit, Auto Reset, 210F E2217700 E2217700 E2217700 E2217700 E2217700 E2217700 E2217700 71 High Limit, Auto Reset, 135F E2104800 E2104800 E2104800 E2104800 E2104800 E2104800 E2104800 72 Relay, Pump (SPST) E0098300 E0098300 E0098300 E0098300 E0098300 E0098300 E0098300 72 Relay, Fan (DPDT) E0076700 E0076700 E0076700 E0076700
(2) (2) (2) (2)
72A Relay, Solid State, (not shown) E2306700 E2306700 E2306700 E2306700 E2306700 E2306700 E2306700 73 Terminal Bus (12 Position) E2310700 E2310700 E2310700 E2310700 E2310700 E2310700 E2310700 74 Transformer E2108700 E2108700 E2108700 E2310400 E2310400 E2310400 E2310400 75 Switch, Rocker E2106600 E2106600 E2106600 E2106600 E2106600 E2106600 E2106600
Sensor E2314300 E2314300 E2314300 E2314300 E2314300 E2314300 E2314300 Gas Train Components See Figure 10
76 Manifold, Gas Supply 5C6100 7C6100 10C6100 12C6100 15C6100 17C6100 20C6100 77 Valve, Ball V2003100 V2003100 V2003200 V2003300 V2003300 V2003300 V2003300
Burner Trays Note: Burner Tray Assemblies contain item numbers 78 through 82. Burner Tray Assembly, 3 Burners, Right, Nat 5C6200 5C6200 5C6200 5C6200 5C6200
(1) (1) (2) (1) (1)
Burner Tray Assembly, 3 Burners, Left, Nat 5C6300 5C6300 5C6300 5C6300 5C6300
(1) (2) (3) (1) (2)
Burner Tray Assembly, 4 Burners, Right, Nat 10C6200 10C6200 10C6200 10C6200
(1) (1) (1) (2)
Burner Tray Assembly, 4 Burners, Left, Nat 10C6300 10C6300 10C6300 10C6300
(2) (2) (2) (4)
Burner Tray Assembly, 3 Burners, Right, LP 5C6220 5C6220 5C6220 5C6220 5C6200
(1) (1) (2) (1) (1)
Burner Tray Assembly, 3 Burners, Left, LP 5C6320 5C6320 5C6320 5C6320 5C6300
(1) (1) (3) (1) (2)
Burner Tray Assembly, 4 Burners, Right, LP 10C6220 10C6220 10C6220 10C6220
(1) (1) (1) (2)
Burner Tray Assembly, 4 Burners, Left, LP 10C6320 10C6300 10C6320 10C6320
(2) (2) (2) (4)
