13 Revision
2 = Second version
14 Heat Exchanger
B = Glass-lined CI / copper / brz trim (std. PM)
K = Bronze / copper
P = Glass-lined cast iron / cu-nickel / brz trim
S = Bronze / cu-nickel
15 Option Code
X = Standard unit
J = CSD-1, FM, IRI, IL
L = MN and LDS (Indoor units only)
16 Pump Options
N = Pump mounted, normal pump
1.3 Warranty
PowerMax appliances are covered by a limited
warranty. The owner should fill out the warranty
registration card and return it to Pentair Water
Commercial Pool and Spa.
All warranty claims must be made to an
authorized Pentair Water Commercial Pool and Spa
epresentative or directly to the factory. Claims must
include the serial number and model (this information
can be found on the rating plate), installation date, and
name of the installer. Shipping costs are not included
in the warranty coverage.
Some accessory items are shipped in separate
packages. Verify receipt of all packages listed on the
packing slip. Inspect everything for damage
immediately upon delivery, and advise the carrier of
any shortages or damage. Any such claims should be
filed with the carrier. The carrier, not the shipper, is
responsible for shortages and damage to the shipment
whether visible or concealed.
1.4 Dimensions
(See Figure 1.)
1.5 Locating the Appliance
The appliance should be located to provide
clearances on all sides for maintenance and inspection.
It should not be located in an area where leakage of
any connections will result in damage to the area
adjacent to the appliance or to lower floors of the
structure.
When such a location is not available, it is
recommended that a suitable drain pan, adequately
drained, be installed under the appliance.
The appliance is design certified by CSA-
International for installation on combustible flooring;
in basements; in closets, utility rooms or alcoves. The
location for the appliance should be chosen with
regard to the vent pipe lengths and external plumbing.
The unit shall be installed such that the gas ignition
system components are protected from water
(dripping, spraying, rain, etc.) during operation and
service (circulator replacement, control replacement,
etc.). When vented vertically, the PowerMax must be
located as close as practical to a chimney or outside
wall. If the vent terminal and/or combustion air
terminal terminate through a wall, and there is
potential for snow accumulation in the local area, both
terminals should be installed at an appropriate level
above grade.
Horizontal Air Collar
Heater Vent Collar Vent Pipe & Pipe Max. Pipe Max. No. Side Wall Side Wall
Size Size Diameter* Diameter Length of Elbows Vent Combustion
Terminal Air Terminal
in.
cm
in.
cm
in
cm
ft.
m
Part Number Part Number
500 8
20
6
15
6
15
50
15
3 CA001401 20260701
750 10
25
8
20
6
15
50
15
3 CA001402 20260701
1000 10
25
8
20
8
20
50
15
3 CA001402 20260703
1250 12
30
8
20
8
20
50 15 3 CA001403 20260703
1500 12
30
8
20
8
20
50
15
3 CA001403 20260703
1750 14 36 8
20
8
20
50 15 3 CA001405 20260703
2000 14
36
12
30
12
30
50
15
3 CA001404 20260706
*Horizontal venting requires stainless vent pipe. See Table 5.
Table 1. Horizontal Vent / Combustion Air Parameters.
