bevel angle. Adjusting the height of the
adjustment screw (15) until the bevel angle is
the correct angle. Finally tighten the nut and
check the angle once more.
Always secure item to be worked with clamps or the
like. Never hold the item to be worked by hand.
Ensure long items are supported.
Set mitre and/or bevel angles as described above if
required.
Check that the saw is correctly set up and that all
handles and bolts are correctly tightened before
starting to saw.
Depress the switch button (11) on the handle, allow
the saw reach full speed before starting to cut.
Pull the lock lever for removable guard (2) and
lower the upper arm to the item .
Do not press the saw sideways.
Release the switch immediately if the blade gets
stuck in the item.
Release the switch when the cut is finished and
wait until the blade has come to a complete stop
before lifting the arm. The removable blade guard
(1) will close automatically when the upper arm is
raised.
Note: The retaining rod can be fitted to either or both sides of the saw de-
pending on which type of cut and work-piece is being used.
