9 CLEANING AND MAINTENANCE
Attention !Before performing any work on the equipment, pull the power
plug.
9.1 Cleaning
 Keep the ventilation slots of the machine clean to prevent overheating of the engine.
 Regularly clean the machine housing with a soft cloth, preferably after each use.
 Keep the ventilation slots free from dust and dirt.
 If the dirt does not come off use a soft cloth moistened with soapy water.
Never use solvents such as petrol, alcohol, ammonia water, etc. These
solvents may damage the plastic parts.
9.2 Carbon brushes
Your POWX1189 is equipped with an electronic ‘worn carbon brush’ warning system. When
the carbon brushes need to be replaced, the indicator (12) lights red. (green=OK)
10 TECHNICAL DATA
POWX1189
Voltage
230-240 V – 50 Hz
nominal power output
1700 W
No load speed
160 -320 min
-1
Rate of percussion (Impacts / min)
950-1900 ipm
Single impact power
27 Joule
Drill capacity concrete
50 mm
Drill capacity steel
13 mm
Drill capacity wood
80 mm
11 NOISE
Noise emission values measured according to relevant standard. (K=3)
Acoustic pressure level LpA
94 dB(A)
Acoustic power level LwA
105 dB(A)
ATTENTION! Wear hearing protection when sound pressure is over 85
dB(A).
aw (Vibration)
18,4 m/s²
K = 1,5 m/s²
12 SERVICE DEPARTMENT
 Damaged switches must be replaced by our after-sales service department.
 If the connecting cable (or mains plug) is damaged, it must be replaced by a particular
connecting cable which is available from our service department. Replacement of the
connecting cable must only be carried out by our service department (see last page) or by
a qualified person (qualified electrician).
