Powersmart DB1002 - Support Assembly

23
SUPPORT ASSEMBLY
Item Stock# Description Qty
1 203021363 8" right wheel cover 1
2 203050544 8" wheel 2
3 303020240 Bolt M8x20 4
4 303181355 Lower tube 1
5 303030087 Lock nut M6 1
6 203070137 Support foot 1
7 303071517 Motor fixing plate 1
8 18013368 Nut M8x18 4
9 303160930A Wheel axle 2
10 303100002 Deep groove ball bearing 4
11 303030077 Lock nut M8 4
12 203021362 8" left wheel cover 1
