Powersmart DB1002 - Housing Assembly

25
HOUSING ASSEMBLY
Item Stock# Description Qty Item Stock# Description Qty
1 301080034
Leakage
protector
1 8 203010933
Power head
upper housing
1
2 301040177 Power cord 1 9 303020077 Bolt M4x10 1
3 303010092 Screw ST4x10 4 10 303240695 Switch 1
4 203021534 Housing 1 11 303043090 Gasket 1
5 203021474
Capacitive
pressure plate
1 12 203021475 Switch cover 1
6 303020490 Bolt M6x25 4 13 303010095 Screw ST4.2x14 3
7 203020047 Cable clamp 2
