KNOWING YOUR LAWN MOWER
Please use the illustration below to familiarize yourself with the location and function of the components
that control of your lawn mower.
1 Recoil starter handle 9 Primer Bulb
2 Grass catcher 10 Fuel tank cap
3 Cutting height adjustment lever 11 Rear discharge door
4 Rear wheel 12 Lower handle
5 Side discharge chute 13 Upper handle
6 Oil dipstick 14 Engine start/stop lever
7 Front wheel 15 Drive control bar
8 Cutting height adjustment lever
15 14 13 12
5 6 7 8
11
10
9
1
2
3
4
