22
M Series User Guide
FIGURE 36: The rst module of an MxxQ device is congured with a 2 in/2 out layout, the second module is congured as a 1 in/2 out. FIGURE 37: The rst module of a MxxQ device is congured with a 2 in/2 out layout with an active monomix. The second module is congured with a 1 in/2 out layout.
